Module Connect

The interface made to measure
The Module Connect is the concept of a new type of plug-in connector for the connection of electrical cables, fibre optic cables and pneumatic hoses. As a cable connector, our modular connector is characterised by a space-saving, flat housing and is used wherever several or a large number of cables are to be plugged into the smallest possible space. The quick connector is concealable without additional coding. Convince yourself of our modular connector.

Made to measure!

Made to measure!

Here you can find all information for the Module Connect!
List
Tile

Number of products: 56

Module Connect 4 cable entries
Module Connect 4 cable entries
Instead of many plug-in/disconnect points in a confined space, only one individually configurable interface
  • Set consists of 5 interfaces or 10 Module Connect plug-in connectors
66,958.70 RSD/Pc.
1 items, thereof ready for shipping from Germany:
1 in 24-48 hours
To the product page

Module Connect 3 cable entries
Module Connect 3 cable entries
Instead of many plug-in/disconnect points in a confined space, only one individually configurable interface
  • Set consists of 5 interfaces or 10 Module Connect plug-in connectors
66,958.70 RSD/Pc.
1 items, thereof ready for shipping from Germany:
1 in 24-48 hours
To the product page

Module Connect fastening element 09140008020
Module Connect fastening element 09140008020
  • Mounting bracket for wall and floor installation as well as housing connection
  • Enables flexible assembly
  • 10-pack with 10 fixing elements
3,153.74 RSD/Pc.
1 items, thereof ready for shipping from Germany:
1 in 24-48 hours
To the product page

Module Connect double locking 09140008022
Module Connect double locking 09140008022
  • Connects and fastens the Module Connect housing
  • 1x Double locking
  • 1x Screw
  • 1x Nut
2,596.03 RSD/Pc.
1 items, thereof ready for shipping from Germany:
1 in 24-48 hours
To the product page

Module Connect single locking 09140008021
Module Connect single locking 09140008021
  • Connects and fastens the Module Connect housing
  • 1x Single locking
  • 1x Screw
  • 1x Nut
1,544.83 RSD/Pc.
1 items, thereof ready for shipping from Germany:
1 in 24-48 hours
To the product page

Module Connect housing 09140048101 / 09140008014 / 09140008013 / 09140048001
Module Connect housing 09140048101 / 09140008014 / 09140008013 / 09140048001
Available housing parts for the Module Connect.
1,543.39 RSD/Pc.
4 items, thereof ready for shipping from Germany:
4 in 24-48 hours
To the product page

Module Connect bellows sealing insert 09140008100 / 09140008200 / 09140008300
Module Connect bellows sealing insert 09140008100 / 09140008200 / 09140008300
Available sealing inserts for the Module Connect.
99.07 RSD/Pc.
3 items, thereof ready for shipping from Germany:
3 in 24-48 hours
To the product page

Module Connect strain relief 09140008034 / 09140008033
Module Connect strain relief 09140008034 / 09140008033
Available strain relief for the Module Connect.
1,104.62 RSD/Pc.
2 items, thereof ready for shipping from Germany:
2 in 24-48 hours
To the product page

Han EE® Quick Lock module 09140122632 / 09140122732
Han EE® Quick Lock module 09140122632 / 09140122732
Number of contacts: 12, silver-plated
Electrical data: 10A / 250V
Connection type: Quick Lock connection
Conductor cross-section: 0.25 ... 1.5mm²
1,870.85 RSD/Pc.
2 items, thereof ready for shipping from Germany:
2 in 24-48 hours
To the product page

Han DD® module 09140123102 / 09140123002
Han DD® module 09140123102 / 09140123002
Number of contacts: 12
Electrical data: 10 A / 250V
Conductor cross-section: 0.14 ... 2.5mm²
Connection type: Crimp connection, Han ® D
438.77 RSD/Pc.
2 items, thereof ready for shipping from Germany:
2 in 24-48 hours
To the product page

Han® DDD module 09140173001 / 09140173101
Han® DDD module 09140173001 / 09140173101
Number of contacts: 17
Electrical data: 10A / 150V
Conductor cross-section: 0.14 ... 2.5mm²
Connection type: Crimp connection, Han ® D
662.69 RSD/Pc.
2 items, thereof ready for shipping from Germany:
2 in 24-48 hours
To the product page

Han DD® Quad module 09140423001 / 09140423101
Han DD® Quad module 09140423001 / 09140423101
Number of contacts: 42
Electrical data: 10A / 150V
Conductor cross-section: 0.14 ... 2.5mm²
Connection type: Crimp connection, Han ® D
1,055.81 RSD/Pc.
2 items, thereof ready for shipping from Germany:
2 in 24-48 hours
To the product page

Han® High Density module 09140253001 / 09140253101
Han® High Density module 09140253001 / 09140253101
Number of contacts: 25
Electrical data: 4 A / 50 V
Conductor cross-section: 0.08 ... 0.52mm²
Connection type: Crimp connection, D-Sub
1,086.34 RSD/Pc.
2 items, thereof ready for shipping from Germany:
2 in 24-48 hours
To the product page

5 A - D-Sub - crimp contacts pin
5 A - D-Sub - crimp contacts pin
5A - D-sub - crimp contacts pin (gold-plated or HMC gold-plated) (PU: 100 pieces)
8,836.42 RSD/Pc.
6 items, thereof ready for shipping from Germany:
1 in 24-48 hours
To the product page

5 A - D-Sub - crimp contacts bushing
5 A - D-Sub - crimp contacts bushing
5A - D-sub - crimp contacts socket (gold-plated or HMC gold-plated) (PU: 100 pieces)
5,789.38 RSD/Pc.
6 items, thereof ready for shipping from Germany:
3 in 24-48 hours
To the product page
